Flame front of a turbulent premixed Bunsen flame from a Direct Numerical Simulation.

Subgrid scale modeling in large-eddy simulation of turbulent combustion using premixed flamelet chemistry. A.W. Vreman, J.A. van Oijen, L.P.H. de Goey and R.J.M. Bastiaans, Flow Turb. Combust. 82, 511-535 (2009). PDF

Reaction activity in a 3D turbulent Bunsen flame: combustion of methane with 40% hydrogen addition.

Direct numerical simulation of hydrogen addition in turbulent premixed Bunsen flames using flamelet generated manifold reduction.
A.W. Vreman, J.A. van Oijen, L.P.H. de Goey and R.J.M. Bastiaans, Int. J. Hydrogen Energy 34, 2778-2788 (2009). Preprint Journal

Temperature in a 3D partially premixed turbulent round jet flame (Sandia Flame D), simulated using the subgrid model that was published in Physics of Fluids (2004).

Premixed and non-premixed generated manifolds in large-eddy simulation of Sandia flame D and F. A.W. Vreman, B.A. Albrecht, J.A. van Oijen, L.P.H. de Goey and R.J.M. Bastiaans, Combust. Flame 153, 394-416 (2008). Preprint Journal
